LS2LR30-600Q8 | TURCK - Your Global Automation Partner
Light Screen for Machine Safety Applications
LS2LR30-600Q8
Order ID nr. 3073557
home
Home
Loading...
Tekniska data
Downloads
Base unit
PCE
EAN/UPC code
662488735579
Gross weight
1980
Height
150
Length
940
Net weight
1980
Dimension unit
MMT
Weight unit
GRM
Volume
21.15
Volume unit
DMQ
Width
150
Ambient temperature max. (°C)
55
Ambient temperature min. (°C)
0
Cascadable
No
Electrical connection
Connector
Connector type
Design
Rectangular
Scan field (mm)
600
Dimensions
31,8 mm x 25,2 mm x 665 mm
Housing material
Metal
Housing quality
AL
Housing surface
Yellow polyester
Start/Restart interlock
yes
Number of beams
32
Function
Light screen
Optical resolution (mm)
30
Output function
Protection class
IP65
Max. range (mm)
15000
With muting function
No
Nyckelfunktioner
Cascadable
No
Scan field (mm)
600
Number of beams
32
Optical resolution (mm)
30
home
Turck-Shop
Machine Safety
Safety Light Curtains
LS2LR30-600Q8
I lager
Varugrupp
G1
Listpris
12 431,00 kr
Totalt för artikeln
12 431,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
