Temperature Detection
TP-103A-N1/8-H1141-L013
Order ID nr. 9910765
I lager
Prisgrupp
D2
Listpris
598,00 kr
Totalt för artikeln
598,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
home
Turck-Shop
Sensors
Temperature Sensors
TP-103A-N1/8-H1141-L013
Tekniska data
Protection class
IP67
Approvals
cULus
Design
Temperature probe
Process connection
1/8″ NPT male thread
Immersion depth L (mm)
13
Detection type
medium contact
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless steel
Housing quality
1.4404 (AISI 316L)
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
120
Mounting conditions
Immersion sensor
Measuring range
-50…120 °C
Electrical output
Resistance
Nyckelfunktioner
Electrical output
Resistance
Process connection
1/8″ NPT male thread
Measuring range
-50…120 °C
