Pressure Sensor
PK012R-N12AL-2UP8X-V1141
Order ID nr. 100042115
I lager
Varugrupp
G1
Listpris
2 971,00 kr
Totalt för artikeln
2 971,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
home
Turck-Shop
Sensors
Pressure Sensors
PK012R-N12AL-2UP8X-V1141
Tekniska data
Protection class
IP65
Switching element function
NO/NC
Output function
PNP
Design
With display
Process connection
G 1/8” female thread
Electrical connection
Connector
Connector type
M8 × 1
Housing material
Aluminium
Housing quality
Al/PVC
Media temperature min.
0
Media temperature max.
60
Ambient temperature min.
-10
Ambient temperature max.
60
Operating voltage
DC
Electrical output
2 × switching output
Pressure type
Relative pressure
Material pressure transducer
Silicon
Pressure range
0…12 bar
Nyckelfunktioner
Electrical output
2 × switching output
Process connection
G 1/8” female thread
Pressure range
0…12 bar
