PT40R-2105-I2-H1144 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT40R-2105-I2-H1144
Order ID nr. 100023805
home
Home
Loading...
Tekniska data
Protection class
IP69K
Output function
Analog output current
Design
Without display
Process connection
7/16″-20 UNF male thread
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Media temperature min. (°C)
-40
Media temperature max. (°C)
125
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
100
Operating voltage
DC
Electrical output
Current output (2-wire)
Pressure type
Relative pressure
Material pressure transducer
Stainless steel 1.4404 (AISI 316L)
Pressure range
0…40 bar
Nyckelfunktioner
Electrical output
Current output (2-wire)
Process connection
7/16″-20 UNF male thread
Pressure range
0…40 bar
I lager
Prisgrupp
J1
Listpris
1 663,00 kr
