Ultrasonic Sensor
LUS211-130-51-2UPN8-H1141
Order ID nr. 100003165
I lager
Varugrupp
D2
Listpris
5 351,00 kr
Totalt för artikeln
5 351,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
home
Home
Loading...
Tekniska data
Protection class
IP67, IP69K
Switching element function
NO/NC
Output function
PNP
Design
Smooth barrel
Process connection
G 3/4''
Medium
liquids, Bulk goods
Detection type
contactless
Communication protocol
IO-Link
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/Grilamid TR90 UV, PA
Ambient temperature min. (°C)
-25
Ambient temperature max. (°C)
70
Max. range (mm)
1300
Measuring principle
Ultrasonic
Function
Proximity switch
Measuring range
1300 mm
Nyckelfunktioner
Communication protocol
IO-Link
Measuring range
1300 mm
Process connection
G 3/4''
Output function
PNP
