LS-534-0200-LIU24PN8X-H1181 | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
Level Sensor
LS-534-0200-LIU24PN8X-H1181
Order ID nr. 100001851
I lager
Listpris
6 143,00 kr
home
Home
Loading...
Tekniska data
Protection class
IP67
Ambient temperature min. (°C)
-20
Ambient temperature max. (°C)
60
Design
With display
Electrical connection
Connector
Operating voltage
DC
Switching element function
NO/NC
Output function
PNP/NPN, analog output
Housing material
Plastic
Communication protocol
IO-Link
Connector type
M12 × 1
Housing quality
PBT
Approvals
UL
Detection type
medium contact
Medium
liquids
Measuring principle
Guided microwave
Process connection
3/4″ NPT male thread
Media temperature min. (°C)
-20
Media temperature max. (°C)
100
Measuring range (mm)
200 mm
Nyckelfunktioner
Communication protocol
IO-Link
Measuring range (mm)
200 mm
Process connection
3/4″ NPT male thread
Output function
PNP/NPN, analog output
home
Turck-Shop
Sensors
Level Sensors
LS-534-0200-LIU24PN8X-H1181
Totalt för artikeln
6 143,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
