Inductive Sensor
NI30U-EM30WDTC-AP6X
Order ID nr. 1634765
I lager
Varugrupp
E2
Listpris
1 389,00 kr
Totalt för artikeln
1 389,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
home
Turck-Shop
Sensors
Inductive Sensors
NI30U-EM30WDTC-AP6X
Tekniska data
Protection class
IP68, IP69K
Switching element function
NO contact
Output function
PNP
Design
Threaded barrel
Electrical connection
Terminal chamber
Connector type
Removable cage clamp terminals
Housing material
Stainless steel
Housing quality
1.4404 (AISI 316L)
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
100
Mounting conditions
Non-flush
Operating voltage
DC
Rated switching distance (mm)
30
Construction size
M30 x 1.5
Nyckelfunktioner
Electrical connection
Terminal chamber
Mounting conditions
Non-flush
Output function
PNP
Rated switching distance (mm)
30
