Inductive Sensor
BI10-M30-IOLU69X2-H1141
Order ID nr. 100001079
I lager
Varugrupp
E1
Listpris
1 927,00 kr
Totalt för artikeln
1 927,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
home
Home
Loading...
Tekniska data
Protection class
IP67
Output function
PNP/NPN, analog output
Design
Threaded barrel
Communication protocol
IO-Link
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Metal
Housing quality
CuZn
Ambient temperature min.
-25
Ambient temperature max.
70
Mounting conditions
Flush
Operating voltage
DC
Measuring range
2
Construction size
M30 x 1.5
Measuring range
2…10 mm
Nyckelfunktioner
Electrical connection
Connector
Measuring range
2…10 mm
Mounting conditions
Flush
Output function
PNP/NPN, analog output
