Freely Rotatable FCST Flow Sensor
FCST-A4P-VRX/230VAC
Order ID nr. 6870254
I lager
Varugrupp
D2
Listpris
3 763,00 kr
Totalt för artikeln
3 763,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
home
Turck-Shop
Sensors
Flow Sensors/Flow Meters
FCST-A4P-VRX/230VAC
Tekniska data
Protection class
IP67
Switching element function
Complementary contact
Output function
Relay output
Cable length (m)
2
Approvals
cULus
Design
Immersion
Process connection
M18 × 1.5 female thread
Medium
liquids
Detection type
Calorimetric
Electrical connection
Cable
Housing material
Plastic
Housing quality
PBT
Media temperature min. (°C)
-20
Media temperature max. (°C)
80
Ambient temperature min. (°C)
-20
Ambient temperature max. (°C)
70
Mounting conditions
Immersion sensor
Operating voltage
AC
Nyckelfunktioner
Process connection
M18 × 1.5 female thread
Output function
Relay output
