FTCI-N3/4D19A4P-2ARX-H1160 | TURCK - Your Global Automation Partner
Flow Rate Monitoring
FTCI-N3/4D19A4P-2ARX-H1160
Order ID nr. 6870053
I lager
Prisgrupp
D2
Listpris
10 571,00 kr
home
Home
Loading...
Tekniska data
Protection class
IP54
Switching element function
NO contact
Output function
Relay output
Design
Inline
Process connection
3/4″ NPT
Medium
liquids
Detection type
Calorimetric
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Plastic
Housing quality
PBT
Media temperature min. (°C)
-10
Media temperature max. (°C)
95
Ambient temperature min. (°C)
-20
Ambient temperature max. (°C)
60
Mounting conditions
Inline sensor
Operating voltage
DC
Nyckelfunktioner
Process connection
3/4″ NPT
Output function
Relay output
