Absolute Rotary Encoder - Singleturn
RES-184S6S-9F14B-H1151
Order ID nr. 100026157
I lager
Varugrupp
F3
Listpris
4 231,00 kr
Totalt för artikeln
4 231,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
home
Turck-Shop
Sensors
Encoders
RES-184S6S-9F14B-H1151
Tekniska data
Protection class
IP67
Communication protocol
SAE J1939
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Die-cast zinc
Ambient temperature min.
-40
Ambient temperature max.
85
Measuring principle
Magnetic
Output type
Absolute singleturn
Shaft Type
Solid shaft
Shaft diameter D (mm)
6
Flange diameter
36
Flange type
Synchro flange
Measuring range
0…360°
Nyckelfunktioner
Output type
Absolute singleturn
Flange diameter
36
Shaft diameter D (mm)
6
Shaft Type
Solid shaft
