BC20-K40WDTC-VP4X2/S930 | TURCK - Your Global Automation Partner
Capacitive Sensor
BC20-K40WDTC-VP4X2/S930
Order ID nr. 2510105
I lager
Prisgrupp
E1
Listpris
2 059,00 kr
home
Home
Loading...
Tekniska data
Protection class
IP69K
Switching element function
Complementary contact
Output function
PNP
Design
Smooth barrel
Electrical connection
Terminal chamber
Connector type
Removable cage clamp terminals
Housing material
Plastic
Housing quality
Grilamid LV-30H FWA
Ambient temperature min. (°C)
-25
Ambient temperature max. (°C)
70
Measuring principle
Capacitive
Mounting conditions
Flush
Operating voltage
DC
Rated switching distance (mm)
30
Construction size
Ø 40 mm
Nyckelfunktioner
Electrical connection
Terminal chamber
Mounting conditions
Flush
Output function
PNP
Rated switching distance (mm)
30
