BC10-S30-Y1X-H1141 | TURCK - Your Global Automation Partner
Capacitive Sensor
BC10-S30-Y1X-H1141
Order ID nr. 2010000
home
Home
Loading...
Tekniska data
Protection class
IP67
Output function
NAMUR
Approvals
TIIS, CSA, FM, IECEx, NEPSI, CE, INMETRO, KOSHA, ATEX
Design
Threaded barrel
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Plastic
Housing quality
PA12-GF30, PEI
Ambient temperature min. (°C)
-25
Ambient temperature max. (°C)
70
Measuring principle
Capacitive
Mounting conditions
Flush
Operating voltage
DC
Rated switching distance (mm)
15
Construction size
M30 x 1.5
Nyckelfunktioner
Electrical connection
Connector
Mounting conditions
Flush
Output function
NAMUR
Rated switching distance (mm)
15
I lager
Prisgrupp
E1
Listpris
1 500,00 kr
home
Turck-Shop
Sensors
Capacitive Sensors
BC10-S30-Y1X-H1141
Totalt för artikeln
1 500,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
