Multibarrier, 4-Channel

MBD40-T0415/EX/000

Order ID nr. 6611757

Protection class: IP66
Network protocol: FOUNDATION fieldbus, PROFIBUS-PA
Application: Data
Approvals: ATEX
Electrical connection: 4 × 3-pin removable terminal blocks, reverse polarity protected, screw terminal, Cable gland
Housing material: Powder-coated die-cast aluminium
Ambient temperature min. (°C): -20
Ambient temperature max. (°C): 70
Number of channels: 4
Installation area: zone 1
Connection technology signal: Cable gland
