Pressure sensor Differential Pressure: 0...10 bar

PS325-10D-04-LI2UPN8-H1141

Order ID nr. 100041104

Ambient temperature max. (°C): 80
Ambient temperature min. (°C): -40
Approvals: cULus
Communication protocol: IO-Link
Connector type
Dimensions: 40 mm
Electrical output: Current output (3-wire), IO-Link, Switching output, Voltage output (3-wire)
Electrical connection: Connector
Housing material: Stainless-steel/Plastic
Housing quality
Materials (contact with media): Stainless steel 1.4404 (AISI 316L), Al₂O₃, FKM
Media temperature max. (°C): 80
Media temperature min. (°C): -30
Output function: PNP/NPN
Pressure range: 0...10 bar
Pressure type: Differential Pressure
Protection class: IP66, IP67, IP69K
Switching element function
