PT1000R-2003-U1-H1141 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT1000R-2003-U1-H1141
Order ID nr. 100024986
home
Home
Loading...
Tekniska data
Downloads
Base unit
PCE
EAN/UPC code
4047101533521
Electrical output
Voltage output (3-wire)
Gross weight
95
Height
40
Length
100
Net weight
95
Dimension unit
MMT
Weight unit
GRM
Volume
0.28
Volume unit
DMQ
Width
70
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-30
Approvals
cULus
Electrical connection
Connector
Connector type
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4435 (AISI 316L)
Media temperature max. (°C)
135
Media temperature min. (°C)
-40
Pressure range
0...1000 bar
Operating voltage
DC
Output function
Analog output voltage
Pressure type
Relative pressure
Protection class
IP67
Nyckelfunktioner
Electrical output
Voltage output (3-wire)
I lager
Varugrupp
J1
Listpris
1 566,00 kr
Totalt för artikeln
1 566,00 kr
