PT0.6R-1504-U1-H1143/D840 | TURCK - Your Global Automation Partner
arrow_back_ios
arrow_forward_ios
Pressure Transmitter
PT0.6R-1504-U1-H1143/D840
Order ID nr. 100024664
home
Home
Loading...
Tekniska data
Downloads
Base unit
PCE
EAN/UPC code
4047101533248
Electrical output
Voltage output (3-wire)
Gross weight
89
Height
40
Length
100
Net weight
89
Dimension unit
MMT
Weight unit
GRM
Volume
0.28
Volume unit
DMQ
Width
70
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-25
Approvals
cULus
Electrical connection
Connector
Connector type
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Media temperature max. (°C)
85
Media temperature min. (°C)
-15
Pressure range
0...0,6 bar
Operating voltage
DC
Pressure type
Relative pressure
Protection class
IP67
Nyckelfunktioner
Electrical output
Voltage output (3-wire)
home
Turck-Shop
Sensors
Pressure Sensors
PT0.6R-1504-U1-H1143/D840
I lager
Varugrupp
D2
Listpris
3 036,00 kr
Totalt för artikeln
3 036,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
