Pressure Transmitter
PT600R-2149-I2-KO28A2
Order ID nr. 100003610
I lager
Varugrupp
J1
Listpris
1 657,00 kr
Totalt för artikeln
1 657,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
home
Turck-Shop
Sensors
Pressure Sensors
PT600R-2149-I2-KO28A2
Tekniska data
Downloads
Base unit
PCE
EAN/UPC code
4047101553925
Electrical output
Current output (2-wire)
Gross weight
90
Height
0
Length
0
Net weight
90
Dimension unit
MMT
Weight unit
GRM
Volume
0
Width
0
Ambient temperature max. (°C)
100
Ambient temperature min. (°C)
-40
Electrical connection
Connector
Connector type
Kostal SLK 2.8 A-coding
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4404 (AISI 316L)
Media temperature max. (°C)
125
Media temperature min. (°C)
-40
Pressure range
0...600 bar
Operating voltage
DC
Output function
Analog output current
Pressure type
Relative pressure
Protection class
IP69K
Nyckelfunktioner
Electrical output
Current output (2-wire)
