Photoelectric Sensor
QMH26VPAF200-5M
Order ID nr. 3028806
I lager
Varugrupp
D1
Listpris
4 922,00 kr
Totalt för artikeln
4 922,00 kr
Kvantitet
−
+
add_shopping_cart
Lägg i kundvagn
Begär offert
home
Turck-Shop
Sensors
Photoelectric Sensors
QMH26VPAF200-5M
Tekniska data
Downloads
Special features
, Wash down, Resistant to chemicals
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-30
Cable length (m)
5
Electrical connection
Cable
Design
Rectangular
Dimensions
20,3 mm x 14 mm x 32,6 mm
Housing material
Metal
Housing quality
Stainless steel
Housing surface
Grey
Light type
Red
Operating mode
Background suppression, adjustable
Output function
PNP
Protection class
IP69
Max. range (mm)
200
Setting option
Screw Adjustment
Switching element function
Complementary contact
Switching frequency (kHz)
2
Wavelength (nm)
660
Nyckelfunktioner
Light type
Red
Output function
PNP
Max. range (mm)
200
