NI20U-EG30SK-AN6X | TURCK - Your Global Automation Partner
Inductive Sensor
NI20U-EG30SK-AN6X
Order ID nr. 1646420
home
Home
Loading...
Tekniska data
Downloads
Special features
uprox+, Factor 1, Resistant to magnetic fields
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-30
Electrical connection
Terminal chamber
Design
Threaded barrel
Construction size
⌀ 30 mm
Housing material
Stainless steel
Housing quality
1.4301 (AISI 304)
Operating voltage
DC
Output function
NPN
Protection class
IP68
Quality active face
PBT
Rated switching distance (mm)
20
Switching frequency (kHz)
1
Nyckelfunktioner
Electrical connection
Terminal chamber
Output function
NPN
Rated switching distance (mm)
20
I lager
Varugrupp
E1
Listpris
1 070,00 kr
