REI-E-111T6C-4A500-C | TURCK - Your Global Automation Partner
Incremental Encoder
REI-E-111T6C-4A500-C
Order ID nr. 100011976
home
Home
Loading...
Tekniska data
Downloads
Base unit
PCE
EAN/UPC code
4047101674262
Gross weight
244
Height
95
Length
110
Net weight
244
Dimension unit
MMT
Weight unit
GRM
Volume
1.202
Volume unit
DMQ
Width
115
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-20
Electrical connection
Cable
Design
Solid shaft
Encoder line
Efficiency-Line
Technology
Optical
Housing material
Aluminium
Output function
Output type
Incremental
Measuring principle
Optical
Protection class
IP64
Flange diameter (mm)
40
Flange type
Synchro/clamping flange
Protection class shaft
IP64
Resolution incremental (ppr)
500
Shaft diameter D (mm)
6 mm
Shaft Type
Solid shaft
Nyckelfunktioner
Output type
Incremental
Flange diameter (mm)
40
Shaft diameter D (mm)
6 mm
Shaft Type
Solid shaft
I lager
Varugrupp
G1
Listpris
1 801,00 kr
Totalt för artikeln
1 801,00 kr
