Bus Cable for CAN (DeviceNet, CANopen)
WSC-WSC5701-1M
Order ID nr. 6931082
home
Home
Loading...
Tekniska data
Downloads
Current (A)
4
Voltage (V)
60
Ambient temperature max. (°C)
60
Ambient temperature min. (°C)
-25
Approvals
UL
Cable color
Anthracite
Core cross-section (mm²)
0.25
Cable diameter (mm)
6.7
Cable length (m)
1
Cable quality
PUR
Plug body
Plastic
Coupling nut/screw material A
Brass
Number of pins
5
Coupling nut/screw material B
Brass
Number of Pins
5
Application
Data
Design
Extension Cable
Network protocol
DeviceNet, CANopen
Nyckelfunktioner
Cable length (m)
1
Cable quality
PUR
I lager
Varugrupp
K1
Listpris
416,00 kr
