Ultrasonic Sensor
RU40U-M18ES-LIU2PN8X2T-H1151
Order ID no. 1610025
In Stock
home
Turck-Shop
Sensors
Ultrasonic Sensors
RU40U-M18ES-LIU2PN8X2T-H1151
Technical Data
Downloads
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-25
Communication protocol
IO-Link
Connector type
M12 x 1
Construction size
⌀ 18 mm
Design
Threaded barrel
Detection type
contactless
Dimensions
107 mm
Electrical connection
Connector
Function
Continuous level measurement, Level detection
Function
Proximity switch
Housing material
Metal
Housing quality
CuZn
Housing surface
Nickel Plated
Max. range (mm)
400
Measuring principle
Ultrasonic
Medium
Bulk goods, liquids
Operating mode
Time-of-Flight
Output function
PNP/NPN, analog output
Protection class
IP67
Quality active face
Epoxy
Radiation direction
side
Resolution
0.5 mm
Setting option
IO-Link, Push Button, Remote Teach
Special features
Pushbutton, Synchronization
Switching element function
NO/NC
Key Features
Communication protocol
IO-Link
Electrical connection
Connector
Output function
PNP/NPN, analog output
Max. range (mm)
400
Group
D2
List Price
4 833,00 kr
Item Total
4 833,00 kr
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
