Pressure Transmitter With Current Output (2-Wire)

PT1000R-2020-IX-DA91

Order ID no. 100019846

Ambient temperature max. (°C): 85
Ambient temperature min. (°C): -25
Approvals: cULus
Connector type: DIN EN 175301-803 Form A
Design: Without display
Electrical output: Current output (2-wire)
Electrical connection: Connector
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer: Stainless steel 1.4435 (AISI 316L)
Media temperature max. (°C): 120
Media temperature min. (°C): -30
Operating voltage: DC
Output function: Analog output current
Pressure range: 0...1000 bar
Pressure type: Relative pressure
Process connection: M20 x1.5 male thread, front sealing and manometer (combi)
Protection class: IP65

Electrical output: Current output (2-wire)
Process connection: M20 x1.5 male thread, front sealing and manometer (combi)
