PT400R-2121-I2-AMPS1.5 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT400R-2121-I2-AMPS1.5
Order ID no. 100015618
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
EAN/UPC code
4047101518894
Electrical output
Current output (2-wire)
Gross weight
90
Height
0
Length
0
Net weight
90
Dimension unit
MMT
Weight unit
GRM
Volume
0
Width
0
Ambient temperature max. (°C)
100
Ambient temperature min. (°C)
-40
Electrical connection
Connector
Connector type
AMP Superseal 1.5
Design
Without display
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Material pressure transducer
Stainless steel 1.4404 (AISI 316L)
Process connection
9/16″-18 UNF male thread
Media temperature max. (°C)
125
Media temperature min. (°C)
-40
Pressure range
0...400 bar
Operating voltage
DC
Output function
Analog output current
Pressure type
Relative pressure
Protection class
IP67
Key Features
Electrical output
Current output (2-wire)
Process connection
9/16″-18 UNF male thread
In Stock
Group
J1
List Price
SEK 1,657.00
