Draw-Wire
DW2000-110-7E-H1441
Order ID no. 1544543
In Stock
Group
B1
List Price
SEK 8,027.00
home
Turck-Shop
Sensors
Linear Position Sensors
DW2000-110-7E-H1441
Technical Data
Protection class
IP65
Output function
Analog output
Design
Draw Wire
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Titanium anodized aluminium
Ambient temperature min. (°C)
-20
Ambient temperature max. (°C)
60
Measuring principle
Potentiometer
Operating voltage
DC
Measuring range (mm)
2000
Output type
Analog
Measuring range
2000…0.0 mm
Base unit
PCE
EAN/UPC code
4047101256888
Gross weight
906
Height
160
Length
230
Net weight
906
Dimension unit
MMT
Weight unit
GRM
Volume
5888
Volume unit
CMQ
Width
160
Key Features
Electrical connection
Connector
Measuring range (mm)
2000
Output function
Analog output
