BI2-EG08K-AN6X-V1131 | TURCK - Your Global Automation Partner
Inductive Sensor
BI2-EG08K-AN6X-V1131
Order ID no. 4669550
home
Home
Loading...
Technical Data
Downloads
Special features
Sn +
Ambient temperature max. (°C)
70
Ambient temperature min. (°C)
-25
Electrical connection
Connector
Connector type
M8 x 1
Design
Threaded barrel
Construction size
⌀ 8 mm
Housing material
Stainless steel
Housing quality
1.4305 (AISI 303)
Mounting conditions
Flush
Operating voltage
DC
Output function
NPN
Protection class
IP67
Quality active face
PA6.6
Rated switching distance (mm)
2
Switching element function
NO contact
Switching frequency (kHz)
3
Key Features
Electrical connection
Connector
Mounting conditions
Flush
Output function
NPN
home
Turck-Shop
Sensors
Inductive Sensors
BI2-EG08K-AN6X-V1131
Rated switching distance (mm)
2
In Stock
Group
E1
List Price
SEK 822.00
Item Total
SEK 822.00
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
