Inductive Sensor
NI12U-M18-ADZ30X2
Order ID no. 4282410
In Stock
Group
E1
List Price
SEK 1,698.00
Item Total
SEK 1,698.00
Quantity
−
+
add_shopping_cart
Add to Cart
Contact Support
home
Turck-Shop
Sensors
Inductive Sensors
NI12U-M18-ADZ30X2
Technical Data
Downloads
Special features
uprox+, Factor 1, Resistant to magnetic fields
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-30
Cable length (m)
2
Electrical connection
Cable
Design
Threaded barrel
Construction size
⌀ 18 mm
Housing material
Metal
Housing quality
CuZn
Housing surface
Chrome-plated
Mounting conditions
Non-flush
Operating voltage
AC/DC
Output function
2-wire
Protection class
IP68
Quality active face
PBT
Rated switching distance (mm)
12
Switching element function
NO contact
Switching frequency (kHz)
0.01
Key Features
Electrical connection
Cable
Mounting conditions
Non-flush
Output function
2-wire
Rated switching distance (mm)
12
