Flow Monitoring
FCS-GL1/2A4-NA-H1141
Order ID no. 6870403
In Stock
Group
D2
List Price
SEK 2,835.00
Item Total
SEK 2,835.00
Quantity
−
+
add_shopping_cart
Add to Cart
home
Turck-Shop
Sensors
Flow Sensors/Flow Meters
FCS-GL1/2A4-NA-H1141
Technical Data
Downloads
Function
Flow monitoring
Detection type
Calorimetric
Application area
Standard
Electrical connection
Connector
Connector type
M12 x 1
Design
Immersion
Dimensions
121,1 mm x 38 mm x 49 mm
Display
4-digit 12-segment display, rotatable by 180°, red or green
Housing material
Stainless steel
Housing quality
1.4571 (AISI 316Ti)
Process connection
G 1/2” long version
Medium
liquids
Media temperature max. (°C)
80
Media temperature min. (°C)
-20
Mounting conditions
Immersion sensor
Protection class
IP67
Key Features
Process connection
G 1/2” long version
