Inductive Sensor

NI12U-GT18-RDZ30X2-B3331

Order ID no. 4281522

Special features: uprox+, Factor 1, Resistant to magnetic fields, PTFE-coated
Ambient temperature max. (°C): 85
Ambient temperature min. (°C): -30
Electrical connection: Connector
Connector type: 1/2″
Design: Threaded barrel
Construction size: ⌀ 18 mm
Housing material: Metal
Housing quality: CuZn
Housing surface: PTFE-coated
Mounting conditions: Non-flush
Operating voltage: AC/DC
Output function: 2-wire
Protection class: IP68
Quality active face: PA12-GF30
Rated switching distance (mm): 12
Switching element function: NC contact
Switching frequency (kHz): 0.01
