K50RPFF50GXDQP | TURCK - Your Global Automation Partner
Pick-to-Light
K50RPFF50GXDQP
Order ID no. 3076219
home
Home
Loading...
Technical Data
Downloads
Base unit
PCE
Special features
I/O module-compatible, Wash down
EAN/UPC code
662488762193
Gross weight
141
Height
60
Length
110
Net weight
141
Dimension unit
MMT
Weight unit
GRM
Volume
0.726
Volume unit
DMQ
Width
110
Ambient temperature max. (°C)
50
Ambient temperature min. (°C)
-40
Cable length (m)
0.15
Electrical connection
Cable with connector
Connector type
M12 x 1
Design
Dome
Construction size
⌀ 50 mm
Dimensions
56,8 mm
Housing material
Plastic
Housing quality
PC
Housing surface
Black
Input type
PNP
Light type
IR
Number of beams
1
Number of colors/segments
1
Function
Limit switch
Operating voltage
DC
Output function
PNP
Protection class
IP67, IP69
Max. range (mm)
50
Switching element function
NC contact
Wavelength (nm)
880
In Stock
Group
F3
List Price
SEK 1,941.00
Item Total
SEK 1,941.00
Quantity
−
+
