RS-53CA0E-9D14B-H1151 | TURCK - Your Global Automation Partner
Absolute Rotary Encoder - Singleturn
RS-53CA0E-9D14B-H1151
Order ID no. 1546535
home
Home
Loading...
Technical Data
Downloads
Special features
Compact
Ambient temperature max. (°C)
85
Ambient temperature min. (°C)
-40
Communication protocol
CANopen
Electrical connection
Connector
Connector type
M12 x 1
Design
Hollow shaft
Encoder line
Industrial-Line
Technology
Magnetic
Housing material
Die-cast zinc
Output type
Absolute singleturn
Measuring principle
Magnetic
Flange diameter (mm)
36
Flange type
Flange with stator coupling
Protection class shaft
IP67
Shaft diameter D (mm)
6.35 mm
Shaft Type
Blind hole shaft
