TTMS-103A-G1/8-LIUPN-H1140-L013-40/85°C | TURCK - Your Global Automation Partner
Temperature Detection
TTMS-103A-G1/8-LIUPN-H1140-L013-40/85°C
Order ID no. 100045325
home
Home
Loading...
Technical Data
Protection class
IP67
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
80
Design
Without display (integrated probe)
Mounting conditions
Immersion sensor
Electrical connection
Connector
Operating voltage
DC
Switching element function
NO/NC programmable
Output function
PNP/NPN
Housing material
Stainless steel
Communication protocol
IO-Link
Connector type
M12 × 1
Housing quality
1.4404 (AISI 316L)
Detection type
medium contact
Process connection
G 1/8'' male thread
Electrical output
Current output (2-wire), Switching output
Immersion depth L (mm)
13
Measuring range
-50…110 °C
Key Features
Communication protocol
IO-Link
Electrical output
Current output (2-wire), Switching output
Process connection
G 1/8'' male thread
Measuring range
-50…110 °C
