Pressure Transmitter

PT100R-2104-I2-MP11

Order ID no. 100049581

Protection class: IP67
Ambient temperature min. (°C): -40
Ambient temperature max. (°C): 100
Design: Without display
Electrical connection: Connector
Operating voltage: DC
Output function: Analog output current
Housing material: Stainless-steel/Plastic
Connector type: Metri Pack 150 P2S series
Housing quality: 1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Approvals: cULus
Process connection: G1/4″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
Media temperature min. (°C): -40
Media temperature max. (°C): 125
Pressure type: Relative pressure
Electrical output: Current output (2-wire)
Material pressure transducer: Stainless steel 1.4404 (AISI 316L)
Pressure range: 0…100 bar

Electrical output: Current output (2-wire)
Process connection: G1/4″ male thread (back sealing) according to DIN EN ISO 1179-2 with FPM profile sealing ring
Pressure range: 0…100 bar
