PT150PSIG-1121-I2-H1143 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT150PSIG-1121-I2-H1143
Order ID no. 100005547
In Stock
List Price
SEK 1,663.00
home
Home
Loading...
Technical Data
Protection class
IP69K
Output function
Analog output current
Approvals
CE, cULus
Design
Without display
Process connection
9/16″-18 UNF male thread
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Media temperature min. (°C)
-40
Media temperature max. (°C)
125
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
100
Operating voltage
DC
Electrical output
Current output (2-wire)
Pressure type
Relative pressure
Material pressure transducer
Ceramic Al₂O₃
Pressure range
0…10.34 bar
Key Features
Electrical output
Current output (2-wire)
Process connection
9/16″-18 UNF male thread
Pressure range
0…10.34 bar
