PT1R-1103-U3-H1143 | TURCK - Your Global Automation Partner
Pressure Transmitter
PT1R-1103-U3-H1143
Order ID no. 100004524
In Stock
List Price
SEK 1,663.00
home
Home
Loading...
Technical Data
Protection class
IP69K
Output function
Analog output voltage
Approvals
CE, cULus
Design
Without display
Process connection
1/4″ NPT-18 male thread
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless-steel/Plastic
Housing quality
1.4404 (AISI 316L)/polyarylamide 50 % GF UL 94 V-0
Media temperature min. (°C)
-40
Media temperature max. (°C)
125
Ambient temperature min. (°C)
-40
Ambient temperature max. (°C)
100
Operating voltage
DC
Electrical output
Voltage output (3-wire)
Pressure type
Relative pressure
Material pressure transducer
Ceramic Al₂O₃
Pressure range
0…1 bar
Key Features
Electrical output
Voltage output (3-wire)
Process connection
1/4″ NPT-18 male thread
Pressure range
0…1 bar
