BI1.5-EH04-0.3-M12-SIU-H1141 | TURCK - Your Global Automation Partner
Inductive Sensor
BI1.5-EH04-0.3-M12-SIU-H1141
Order ID no. 1533001
home
Home
Loading...
Technical Data
Protection class
IP67
Output function
Analog output
Cable length (m)
0.3
Design
Smooth barrel
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Stainless steel
Housing quality
1.4427 SO
Ambient temperature min. (°C)
-25
Ambient temperature max. (°C)
70
Mounting conditions
Flush
Operating voltage
DC
Measuring range (mm)
0.1
Construction size
Ø 4 mm
Measuring range
0.1…1.5 mm
Key Features
Electrical connection
Connector
Measuring range
0.1…1.5 mm
Mounting conditions
Flush
Output function
Analog output
In Stock
Price Group
E1
List Price
SEK 2,240.00
