Flow Sensor

FS100-300L-58-2LI-H1141

Order ID no. 100029676

Protection class: IP66, IP67, IP69K
Output function: Analog output
Approvals: CE, cULus
Design: With display (integrated probe)
Process connection: 1/2″ NPT male thread
Immersion depth L (mm): 64.9
Medium: liquids
Electrical connection: Connector
Connector type: M12 × 1
Housing material: Stainless-steel/Plastic
Housing quality: 1.4404 (AISI 316L)/Grilamid TR90 UV/Elastollan C 65 A 15 HPM 000/Ultramid A3X2G5
Media temperature min. (°C): -25
Media temperature max. (°C): 85
Ambient temperature min. (°C): -40
Ambient temperature max. (°C): 80
Mounting conditions: Immersion sensor
Electrical output: Current output (3-wire), Current output (3-wire)
