RES-183B8T-3C13B-H1181 | TURCK - Your Global Automation Partner

Absolute Rotary Encoder - Singleturn

RES-183B8T-3C13B-H1181

Order ID no. 100016347

homeHome
Loading...

Protection class: IP67
Ambient temperature min. (°C): -40
Ambient temperature max. (°C): 85
Electrical connection: Connector
Housing material: Die-cast zinc
Communication protocol: SSi
Connector type: M12 × 1
Measuring range: 0…360°
Output type: Absolute singleturn
Shaft Type: Blind hole shaft
Shaft diameter D (mm): 8
Flange diameter (mm): 36
Flange type: Flange with mounting element
Measuring principle: Magnetic

Key Features

Output type: Absolute singleturn
Flange diameter (mm): 36
Shaft diameter D (mm): 8
Shaft Type: Blind hole shaft

homeTurck-Shop
Sensors
Encoders
RES-183B8T-3C13B-H1181

In Stock
Price Group	F3
List Price	SEK 4,489.00

Item TotalSEK 4,489.00

Quantity

Contact Support
