RES-186SA0S-3C13B-H1181 | TURCK - Your Global Automation Partner

Absolute Rotary Encoder - Singleturn

RES-186SA0S-3C13B-H1181

Order ID no. 100016319

homeHome
Loading...

Protection class: IP67
Ambient temperature min. (°C): -40
Ambient temperature max. (°C): 85
Electrical connection: Connector
Housing material: Die-cast zinc
Communication protocol: SSi
Connector type: M12 × 1
Measuring range: 0…360°
Output type: Absolute singleturn
Shaft Type: Solid shaft
Shaft diameter D (mm): 6.35
Flange diameter (mm): 58
Flange type: Synchro flange
Measuring principle: Optical

Key Features

Output type: Absolute singleturn
Flange diameter (mm): 58
Shaft diameter D (mm): 6.35
Shaft Type: Solid shaft

In Stock
Price Group	F3
List Price	SEK 5,990.00
