LS2LR30-300Q8 | TURCK - Your Global Automation Partner
Safety Light Curtain
LS2LR30-300Q8
Order ID no. 3073555
home
Home
Loading...
Technical Data
Protection class
IP65
Switching element function
2 x NC contact
Output function
2 × PNP
Design
Rectangular
Electrical connection
Connector
Connector type
M12 × 1
Housing material
Metal
Housing quality
AL
Ambient temperature min. (°C)
0
Ambient temperature max. (°C)
55
Max. range (mm)
15000
Function
Light screen
Scan field (mm)
1800
Optical resolution (mm)
30
Construction size
31.8 x 25.2 x 365 mm
Cascadable
No
Start/Restart interlock
yes
With muting function
No
Number of beams
16
Key Features
Cascadable
No
Scan field (mm)
1800
Optical resolution (mm)
30
Number of beams
16
In Stock
List Price
SEK 7,380.00
