Temperature measuring amplifier

IM34-14EX-CDRI

Order ID no. 7506634

Protection class: IP20
Approvals: ATEX, IECEx, cFMus, TIIS, TR CU, Metrological Approval Russia, KOSHA
Electrical connection: 4 × 5-pin removable terminal blocks, reverse polarity protected, screw terminal
Housing material: Plastic
Housing quality: Polycarbonate/ABS
Ambient temperature min. (°C): -25
Ambient temperature max. (°C): 70
Power supply: widerange
Number of channels: 1
Ex version: yes
Signal type: Temperature input
Nominal voltage: Wide voltage range
Approvals: ATEX, IECEx, cFMus, TIIS
Digital output: Relay output
