Actuator and Sensor Cable, PUR

RKSV4.5T-2-RSSV4.5T/TXY3013

Order ID no. 6632920

Ambient temperature min. (°C): -25
Ambient temperature max. (°C): 80
Cable length (m): 2
Application: Signal
Voltage: 60
Special features: Shielded, Shielding on coupling nut, Suitable for drag chain use
Approvals: cULus
Number of pins: 5
Coupling nut/screw material A: Stainless Steel
Number of Pins: 5
Coupling nut/screw material B: Stainless Steel
Current (A): 4
Cable quality: PUR
Cable color: Yellow
Design: Extension Cable
Connector A: Female, M12 × 1, Straight, A-coded
Connector B: Male, M12 × 1, Straight, A-coded
Core cross-section (mm²): 0.34
Number of Conductors: 5
