Flow Sensor

FS101-300L-30-2UPN8-H1141

Order ID nr. 100030867

Ambient temperature max. (°C): 80
Ambient temperature min. (°C): -40
Approvals: CE, cULus
Bar length (mm): 45
Communication protocol: IO-Link
Connector type
Dimensions: 141,4 mm x 38 mm x 49 mm
Electrical output: IO-Link,
Electrical connection: Connector
Housing material: Stainless-steel/Plastic
Housing quality
Immersion depth L (mm): 16.9
Materials (contact with media): Stainless steel 1.4571 (AISI 316Ti), FKM O-ring, AFM flat seal
Media temperature max. (°C): 85
Media temperature min. (°C): -25
Mounting conditions: Immersion sensor
Output function: PNP/NPN
Protection class: IP66, IP67, IP69K
